工藝特性
◆ 理想的單/多通道式或循環式生產工藝，連續不斷的高效能實現了粒徑的最窄化分布；
◆ 渦輪加速器使研磨珠產生有力的流體運動，從而保證了持續恒定的能量輸入；
◆ 能量利用率高，整機能耗低；
◆ 可以處理從低到高粘度的物料；
◆ 理想的冷卻特性允許處理對溫度敏感物料；
◆ 研磨珠的獨特流體運動保障了流暢的研磨過程。
Properties of the Process
◆ Designed for running in single/multi-pass or circulation, with a constant efficiency in both processes for the achievement of narrow particle size distributions.
◆ Turbine accelerator a powerful, hydraulic movement of the beads which guarantee a high and constant energy input.
◆ The mill has a low energy uptake due to its ef?cient energy input.
◆ Ability to handle low to highly viscous products.
◆ Ideal cooling properties allow the processing of temperature sensitive products.
◆ Gentle processing as a result of hydraulic movement of the beads.
優勢表現
◆ 更高的流量；
◆ 更好的高粘度物料處理能力；
◆ 更長的分離篩網壽命；
◆ 提高了對發泡物料處理能力；
◆ 在納米范圍內的研磨能力；
◆ 在生產中維護保養簡單快捷；
◆ 低成本的物料切換；
◆ 通道模式和循環模式的優化組合。
Superiority performance
◆ Much higher throughputs.
◆ Better ability to process highly viscous products.
◆ Longer lifetime of the screen.
◆ Improved ability to handle foaming products.
◆ Ability to grind in the nanometre range.
◆ Simple handling of the machine during the production and the maintenance.
◆ Possibility for fast product changes at low costs.
◆ Optimal suitability for the pass mode and the circulation mode.
應用領域 Application domain
● 油漆和清漆 | ● 醫藥學 | ● Paints and varnishes | ● Pharmaceutical |
技術參數 Technical parameters
| 型號 Type | TN-2 | TN-10 | TN-18 | TN-30 | TN-60 |
研磨腔容積 | 2 | 10 | 18 | 30 | 60 |
主機功率 | 5.5~7.5 | 15~22 | 30~37 | 37~45 | 55~90 |
冷卻水消耗 | 1000~1500 | 1500~2200 | 1800~2500 | 2500~3000 | 3000~4000 |
