優勢廣泛的應用
帶有鮮明色彩和高分辨率的時尚手機、TFT屏或筆記本電腦、以及大量時尚汽車漆和色彩鮮明的涂料的杰出質量實顯著該機型優秀的分散特性。被更多地應用在油漆和清漆、農用化工、油墨、化工、造紙和納米科技領域。
◆ TFT屏和PLC顯示屏的高質量濾色器；
◆ 更具光彩的汽車漆，高固體份和水基產品；
◆ 具有更高抵抗力的重型涂料；
◆ 對高光敏顏料的納米級研磨使其更光輝奪目；
◆ 在高質量染色漿料的生產中加強著色力能帶來更多的經濟效益；
◆ 更具光澤度和透明度的高質量包裝和銀箔油墨；
◆ 更高品質的特級噴墨產品；
◆ 在研究和生產中取得更高的質量和經濟效益，在百分數和研磨具有高要求的產品研制。
Advantage: a wide range of applications
The excellent quality of bright-colored and high-resolution fashion mobile phones, TFT screens or laptops, and a large quantity of fashion automotive paint and bright-colored paint really show the outstanding dispersion characteristic of the model. It is more used the fields of paints and varnishes, agricultural chemicals, inks, chemicals, paper making and nanotechnology
◆ High-quality color filter of TFT screen and PLC display screen;
◆ More glorious car paint, high solids and water-based products;
◆ Heavy coatings with higher resistance;
◆ Nano-level grinding of photosensitive pigment makes it more brilliant, eye-catching;
◆ In the production of high-quality dyeing paint, the enhanced color strength can lead to more economic benefits;
◆ High-quality packaging and silver2 ink with more gloss and transparency;
◆ Super inkjet products with higher quality;
◆ Obtaining higher quality and economic benefits in research and production, with high requirements of product development in percentage and grinding.
快速簡單的操作
該機操作簡單、極易掌握，所有維修工作都可以快速而容易地完成。
◆ 研磨介質非常方便地從上面的填孔加入；
◆ 不用卸料和研磨介質，就可以從封閉的研磨機中取出保護篩網；
◆ 在產品更換中只需要極少的清潔液；
◆ 在研磨介質更換時所需的時間和清洗最少；
◆ 通過整體式提升裝置使研磨腔的下降非常簡便；
◆ 研磨腔可以下降并沿軸樞旋轉。
Quick and easy operation
The model is simple, easy to master, and all the maintenance can be completed quickly and easily.
◆ It is very easy to add grinding media from the filling hole above;
◆ Do not discharge and grind the media, but the protective screen can be taken out of the closed mill;
◆ Minimal cleaning fluid is required for replacement of the product;
◆ Minimum time and cleaning are required for replacement of grinding media;
◆ It is very simple to make the grinding chamber decline by an integral lifting device;
◆ The grinding chamber can drop and rotate along the pivot.
技術參數 Technical parameters
| 型號 Type | DCD12 | DCD100 | DCD200 | DCD400 | DCD800 |
| 主機功率 Main unit power (kw) | 5.5 | 22~30 | 45~55 | 90~110 | 250 |
| 研磨缸容積 Tank capacity (L) | 1.2 | 10 | 17 | 30 | 79 |
| 產品最高流量 Maximun ?ow rate (L/h) | 300 | 1200 | 3000 | 6000 | 12000 |
